Biostar H510MHP 2.0 Ver. 6.0 LGA 1200 Micro-ATX Intel Motherboard, Intel H510 Chipset
Product Overview for Biostar H510MHP 2.0 Micro-ATX Intel Motherboard
The BIOSTAR H510MHP 2.0 Ver. 6.0 is a Micro-ATX format motherboard leveraging the Intel H510 chipset and LGA 1200 socket, enabling support for 10th and 11th generation Intel Core, Pentium and Celeron processors. With dual DDR4 DIMM slots capable of accommodating up to 64 GB of memory and speeds up to 3200 MHz, it offers solid upgrade potential for compact or value-oriented systems. Storage flexibility is built-in via one M.2 socket supporting PCIe 3.0×4 and SATA SSDs, alongside four SATA III ports for more traditional drives. Expansion options include a full-length PCIe 3.0/4.0 x16 slot and two PCIe 3.0 x1 slots, while the rear I/O delivers HDMI, VGA, PS/2 ports, USB 3.2 Gen1, USB 2.0, and Gigabit LAN via Intel I219V controller. Its compact size (approximately 18.5 cm × 22.6 cm) makes it suitable for space-constrained builds, yet it retains the essential connectivity and performance features needed for a gaming, home office or mainstream PC build in the UAE.
Technical Specifications – Essential Features for Home and Office Builds
| Chipset | Intel H510 |
| CPU SUPPORT | Socket 1200 for 10th / 11th Gen Intel Core™, Pentium, and Celeron processors |
| MEMORY |
Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2666/ 2933/ 3200 |
| STORAGE | 4 x SATA III Connector (6Gb/s) 1 x M.2 (M Key) Socket: Supports M.2 Type 2242/ 2260/ 2280 SSD module Supports PCIe 3.0 x 4 (32Gb/s) & SATA III (6Gb/s) SSD * When using SATA SSD module on PCIe-M2_1 slot, the SATA_1 connector will be disabled |
| LAN | Intel I219V 10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability |
| AUDIO CODEC | Realtek ALC897 7.1 Channels, High Definition Audio |
| USB | 4 x USB 3.2(Gen1) ports (2 on rear I/Os and 2 via internal headers) 6 x USB 2.0 ports (4 on rear I/Os and 2 via internal headers) |
| EXPANSION SLOT | 2 x PCIe 3.0 x1 Slot 1 x PCIe 3.0/4.0 x16 Slot * PCIe 4.0 depends on Rocket Lake CPUs |
| REAR I/O | 1 x PS/2 Keyboard 1 x PS/2 Mouse 1 x HDMI Port 1 x VGA Port 2 x USB 3.2 (Gen1) Ports 4 x USB 2.0 Ports 1 x LAN port 3 x Audio Jack |
| INTERNAL I/O | 4 x SATA III Connectors (6Gb/s) 1 x USB 2.0 Header (each header supports 2 USB 2.0 ports) 1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports) 1 x 8-Pin Power Connector 1 x 24-Pin Power Connector 1 x CPU Fan Connector 1 x System Fan Connector 1 x Front Panel Header 1 x Front Audio Header 1 x Clear CMOS Header 1 x COM Port Header |
| H/W MONITORING | CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control CPU/DDR Voltage Monitoring |
| ACCESSORIES | 2 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x Quick Guide |
Key featuers for Biostar H510MHP Intel Motherboard
- Supports 10th/11th Gen Intel Core, Pentium, and Celeron processors
- Dual DDR4 memory slots up to 64GB
- PCIe 3.0 support for GPU or SSDs
- SATA ports for storage flexibility
- HDMI and VGA outputs for dual display setups
- Supports USB 3.2 Gen1
Payment & Delivery
Available on ArabGamers.ae
Free delivery across UAE (1–2 working days)
Payment options: Cash on Delivery and Card Payment
Warranty & Support
Includes 1-Year Warranty
Contact: +971 58 665 1195
