ASUS Z890-AYW Gaming WiFi W Motherboard, Intel Z890 Chipset, LGA1851 Socket, DDR5 Support, PCIe 5.0, WiFi, 2.5Gb Ethernet, ATX Gaming Motherboard | 90MB1I60-M0AAY0

Product Overview for ASUS Z890-AYW Gaming WiFi W Motherboard

The ASUS Z890-AYW Gaming WiFi W Motherboard is designed for modern Intel desktop platforms, delivering reliable performance, advanced connectivity, and stable power delivery for gaming systems and professional workloads. Built on the Intel Z890 chipset, this ATX motherboard supports the latest Intel Core processors on the LGA1851 socket, along with high-speed DDR5 memory, PCIe 5.0 expansion, and fast storage options.

With integrated WiFi connectivity, 2.5Gb Ethernet networking, and multiple high-speed USB ports, the ASUS Z890-AYW Gaming WiFi W provides a strong foundation for gaming PCs, creator workstations, and high-performance builds. ASUS thermal solutions, optimized power delivery, and intelligent tuning help maintain stable system performance during demanding tasks.

Technical Specifications for ASUS Z890-AYW Gaming WiFi W Motherboard, UAE

Model	Z890 AYW GAMING WIFI W
CPU	Supports Intel Core Ultra Processors(Series 2), LGA1851 Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
Chipset	Intel Z890 Chipset
Memory	4 x DIMM slots, max. 256GB, DDR5 Supports up to 9066+MT/s (OC),  Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)* Dual channel memory architecture DIMM Fit Supports Intel® Extreme Memory Profile (XMP) memory module ASUS Enhanced Memory Profile III(AEMPIII)
Graphics	1 x DisplayPort 1 x USB 20Gbps port (USB Type-C) supports DisplayPort video output
Expansion Slots	Intel Core Ultra Processors(Series 2) 1 x PCIe 5.0 x16 slot Intel Z890 Chipset 2 x PCIe 4.0 x16 slots (supports x4 mode) 1 x PCIe 4.0 x16 slot (supports x1 mode)
Storage	Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports* Intel® Core™ Ultra Processors(Series 2) * M.2_1 slot (Key M), type 2280/22110 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode) Intel® Z890 Chipset M.2_3 slot (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode) M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 & SATA modes) 4 x SATA 6Gb/s ports
Ethernet	1 x Realtek 2.5Gb Ethernet ASUS LANGuard
Wireless & Bluetooth	Wi-Fi 6 (802.11 a/b/g/n/ac/ax) Supports 2.4/5GHz frequency band Bluetooth v5.3
USB	Rear USB (Total 8 ports) 1 x USB 20Gbps port (1 x USB Type-C® with DP Alt mode)* 3 x USB 10Gbps ports (3 x Type-A) 4 x USB 2.0 ports (4 x Type-A)*** Front USB (Total 9 ports) 1 x USB 20Gbps connector (supports USB Type-C® with up to 30W PD/PPS Fast-charge )** 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports
Audio	Realtek 7.1 Surround Sound High Definition Audio CODEC - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback Audio Features - Audio Shielding - Premium audio capacitors - Dedicated audio PCB layers
Internal I/O Connectors	Fan and Cooling Related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 4 x 4-pin Chassis Fan headers Power Related 1 x 24-pin Main Power connector 2 x 8-pin +12V CPU Power connectors Storage Related 4 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 20Gbps connector (supports USB Type-C® with up to 30W PD/PPS Fast-charge ) 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports Miscellaneous 3 x Addressable Gen2 headers 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (F_AUDIO) 1 x S/PDIF Out header 1 x SPI TPM header (14-1 pin) 1 x 10-1 pin Front Panel System header 1 x Thunderbolt™ (USB4®) Header
Back Panel I/O Ports	1 x USB 20Gbps port (1 x USB Type-C with DP Alt mode) 3 x USB 10Gbps ports (3 x Type-A) 4 x USB 2.0 ports (4 x Type-A) 1 x DisplayPort 1 x Wi-Fi module 1 x Realtek 2.5Gb Ethernet port 3 x Audio jacks 1 x BIOS FlashBack™ button

Key Features - ASUS Z890-AYW Gaming WiFi W Motherboard

• Intel Z890 Chipset Platform

• High-Speed DDR5 Memory Support

• PCIe 5.0 Expansion Support

• Integrated WiFi Connectivity

• 2.5 Gigabit Ethernet LAN

• Multiple M.2 Storage Slots

• ASUS Thermal & Power Design

• Comprehensive I/O Connectivity
